SMD Sinking Plate Type 8P8C Modular Female RJ45 LED Connector DGKYDCB421188GWW6SB1075

Quantidade de ordem mínima :	Negociação	Preço :	Please contact us to get the latest price.
Detalhes da embalagem :	Bandeja 1080 na caixa	Tempo de entrega :	20 dias
Termos de pagamento :	T/T, D/P, D/A, L/C, Western Union, MoneyGram	Habilidade da fonte :	100 mil peças/dia

Lugar de origem:	DongGuan da China	Marca:	DGKYD
Certificação:	RoHS/CE/UL/FCC/CE/ISO9001/ISO14001	Número do modelo:	DGKYDCB421188GWW6SB1075

Informação detalhada
Número da parte:	Conector SMD Ethernet RJ45	Habitação:	LCP
Número de núcleos:	8	Cor do LED:	não
Número de pinos:	8	Marca:	DGKYD
Revestimento de contacto:	Revestimento de G/Fu	Nomenclatura de tensão:	125 V
Temperatura de armazenamento:	- ℃ 40 ~ ℃ 85	Resistência de Contato:	30milliohm no máximo
Fechadura:	TAB-Up
Destacar:	Modular Female RJ45 LED Connector , SMD Sinking Plate RJ45 LED Connector , Sinking Plate Type RJ45 Connector

Descrição de produto

sinking plate type rj45 8P8C female led connector rj45 modular jack DGKYDCB421188GWW6SB1075

Parameters

Part Number	DGKYDCB421188GWW6SB1075	Brand	DGKYD/OEM/ODM
Place of Origin	Guangdong of China	Certification	RoHS/CE/FCC/CE/ISO9001/ISO14001
Product Type	Connector-Modular	Connector Style	Jack
Jack Type	RJ45	Connector Type	Modular Jack
Latch Style	Standard	Latch	TAB-up
Filter	Without Filter	LED Option	Without LED
LED Color	No	Panel Stops	With Panel Stops
Shielded	Yes	Applies To	Printed Circuit Board
Performance Speed	10/100/1000 BASE-T/TX	Suitable for welding type	Reflowsolding(Alternative).
Port Configuration	single Ports	Number of Positions	8
Jack Configuration	1X1	Terminals per Port	8
Shield Material	Copper Alloy preplated with Nickel	PCB Mounting Orientation	Side Entry (Right Angle)
Contact Mating Area Plating Material	Gold 6u/15u/30u/50u	Contact Base Material	Phosphor Bronze
Solder Tail Contact Plating Material	Tin-Lead over Nickel	PCB Mounting Style	Through Hole
Termination Method to PC Board	Through Hole-Press-Fit	Board Lock	WithWithout Board Lock
Housing Material	LCP Polyester	Housing Color	Black
Housing Material Temperature	Standard	UL Flammability Rating	UL 94V-0

Drawings

SMD Sinking Plate Type 8P8C Modular Female RJ45 LED Connector DGKYDCB421188GWW6SB1075 0

FAQ:

1. Q: Are you trading company or manufacture?
A: We are manufacture. Welcome to our factory.

2. Q: What about your lead time?
A: For products in stock, the goods will be delivered within 5-7 working days after payment. For customized products and products that are out of stock, the delivery time should be confirmed according to your order quantity.

3. Q: Can you provide samples? Are they free?
A: Yes. Usually we can provide 2-3 samples of standard products free for testing.

4. Q: Can I put my own logo on it?
A: Yes. As a manufacturer with 11-year OEM experience, we are fully capable of customizing products for you.
